DI Port 4G TCP Rs485 Modbus Rtu Industrial Cellular Modem

Name: DI Port 4G TCP Rs485 Modbus Rtu Industrial Cellular Modem
Brand: IOTROUTER
Price: 75 USD

Best DI Port 4G TCP Rs485 Modbus Rtu Industrial Cellular Modem wholesale

Brand Name : IOTROUTER

Model Number : ZHC4922

Certification : CE FCC RoHs

Place of Origin : Sichuan, CHINA

MOQ : 1PCS

Price : USD75~79/PCS

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50000PCS/MONTH

Delivery Time : 1 WEEK

Packaging Details : 270*180*55mm CARTON PACKAGE

Product Name : Modbus TCP 4G RTU

Interface : RS485/4DI/4DO/4AI

Protocol : MQTT/MODBUS TCP

Function : Transparent Transmission

Application : IOT Monitoring

Working Voltage : 12V

Module Type : 4G LTE

Color : Black

Accessories : Power Adapter/Antenna

Material : Galvanized Steel Sheet

Contact Now

Modbus TCP 4G RTU Industrial Cellular Modem with RS485 DI Ports

Introduction of 4G RTU

4G RTU, ZHC4922 is a super cost-effective industrial-grade wireless data terminal product. It uses LTE 4G wireless network as the bearer network to provide users with wireless data transmission channels over TCP/IP, which can complete remote monitoring station serial devices and centers Wireless data communication between monitoring systems enables remote device monitoring to be realized. This product is particularly suitable for data collection and monitoring of distributed unattended field equipment, such as: environmental monitoring, smart water services, weather monitoring, street lamp monitoring, heating and heating monitoring, self-service terminal networking.

Parameters of 4G RTU

Serial Port		DO
Number of ports	RS485*1	Number of interfaces	4 Relay output
Standard	RS485: A, B	Standard	DO1, COM2
Baud rate	600～921600bps	Mechanical durability	10^7
Data bit	8, 9	Electrical durability	10^5
Stop bit	0.5, 1, 1.5, 2	Capacity	5A 250VAC 30VDC
Check Bit	NONE EVEN ODD	DI
Power Supply		Number of interfaces	4 Relay input
Voltage	9~36V	Standard	DI4, COM2
Current	60mA(aver) @9V 30mA(aver) @36V	Detection range (wet node)	5~50V->High0~2V->Low
EMC		AI
ESD	IEC61000-4-2, Level 4	Number of Interfaces	4 Analog input
Surge	IEC61000-4-2, Level 3	Standard	AI4, COM2
Group pulse	IEC61000-4-2, Level 3	Scope of test	4~20mA
Equipment Port
SIM Card		1.8V/3V
LTE Antenna		SMA

Features of 4G RTU

Collection function:

-Collect analog standard signals such as pressure and water level transmitters, 4-20mA signals (default)
-Collect data from 485 meters such as flow meters and electricity meters
-Support fixed-point/timing acquisition, freely configure acquisition/frequency
-Incompatible instrument protocols can be instrument-driven development

DI Port 4G TCP Rs485 Modbus Rtu Industrial Cellular Modem

	4G RTU
RS485 Modbus	√
RS485 Automatic Acquisition	√
Virtual Serial Port	√
Connfiguration Software	√
Threshold Report	√
Configuration Software Docking	√
Modbus RTU/TCP	√
